1.0 Engine Details

Kohler KDI1903TCR, 57HP

Transmission System

Hydraulic converter + drive shaft + axles

3.0 Bucket

Bucket Capacity: 0.65 m3

Bucket width: 1700mm

Bucket type:Heavy-duty bolt on teeth

Rated Load: 1500kg/1800kg including attachment

4.0   Overall Dimensions

Overall Length: 4320mm

Overall Height:2670mm

Overall Width: 1720mm

Max. lifting Height:4250mm

5.0 Operating Specifications

Steering System: Articulated Frame with hydraulic power steering

Min Turning Radius: 4950mm

Driving System: Hydraulic converter, four wheel drive

Quick coupling system

Joystick

Self levering

6.0 Brake System

Service Brake:Four Wheel Chuck brake

Parking Brake:Hand operated

7.0 Tyre

Model:12-16.5, 12ply (2)Width: 307mm(3) Diameter: 831mm

8.0 Wheelbase: 2400mm

9.0 Track: 1345mm

10.0 system pressure:20Mpa; Hydraulic output:70L/min
