Overall weight(kg) 2000

 Operating weight(kg) 2500

L×W×H（mm） 4280×1460×2300MM

LxBxH (mm)     4280x1560x2500MM*

4 wheel drive, more flexible and advanced.

Hydrostatic transmission Optional

Rated bucket capacity(m3) 0.6

Rated load(kg) 800-1000

Dump height (mm) 2200

Lifting height(mm) 2650

Dump distance 700mm

Wheelbase 2100mm

Thread 1405mm

Total time 11s

Engine Type

Direct injection, horizontal, water-cooled,

four stroke, 3 cylinders

Rated power  34hp (50hp)*

Rated speed(r/min) 2200

Working system

Steering system

Type Articulated hydraulic steering

Max. turning angle 280±1

Min turning radius(mm) 3200

Standard tires 750-16

Optional.

Larger cabin*

Hydrostatic transmission

Tires 10-16.5

Tires 31X15.5-15*
