Overall Dimension

Length*Width * Height 5910*2268*3760(mm)

Wheel base 2250(mm)

Track 1640(mm)

Min. ground clearance 300(mm)

Main Technical Specification

System pressure

Load hydraulic system 18Mpa

Dig hydraulic system 20Mpa

Steering hydraulic system 12Mpa

System flow 120L/min

Four-wheel drive,Whole hydraulic system

Total operating weight 7600kg

Maximum gradient capacity 30°

Loading bucket capacity 1m3

Rated loading 2500KG

Maximum articulated height of bucket 3400（mm）

Bucket discharge height 2795(mm)

Diesel engine

Model Cummins

Type Turbocharging four-stroke

Rated power 74KW/100HP

Rated speed 2200 r/min

Cylinder –internal diameter 4—110

Maximum torque 310N.M

Minimum fuel consumption 245g/kw.h

Displacement 4.5L
