Performance

1 Rated load 4500kg

2 Overall weight 10.000kg

3 Max Lifting Height 5530mm

4 Max. Dumping height 4480mm

5 Bucket Max Tipping Angel 42.5°

6 Overall dimension L-7800 x W-2420 x H-3230mm

7 Min. Turning radius 35"

8 Engine  Cummins

9 Type Inline/Turbocharged

10 Rated power, depends on the engine size

11 Transmission System Hydraulic Converter  + drive shaft + axels

12 Speed 0-36km*

13 Wheel base 2845mm

14 Wheel track 1825mm

15 System working pressure 19MPa

16 Fuel tank capacity 175L

17 Hydraulic tank capacity 150L

18 Service brake Air over hydraulic disc brake on 4 wheels

19 Parking brake Mechanical control band brake Tyre

20 Type 17.5-25

21 Front tyre pressure 0.34Mpa

22 Rear tyre pressure 0.29Mpa
